SVOLT 5.43kWh 51.2V 106Ah A-Grade LiFePO4 Battery – High-Performance Energy Storage
Description:
The SVOLT 5.43kWh 51.2V 106Ah Lithium Iron Phosphate (LiFePO4) Battery is a high-efficiency energy storage solution designed for residential, commercial, and industrial applications. Manufactured with A-Grade lithium cells, this battery delivers superior performance, reliability, and a long lifespan. Ideal for solar energy storage, electric vehicles, medical equipment, telecommunications, and uninterruptible power supplies (UPS), it ensures consistent and maintenance-free operation.
Key Features:
- A-Grade LiFePO4 Cell Technology: Provides high efficiency, durability, and long cycle life.
-
Long-Lasting Performance:
- Over 4,000 charge cycles at 80% Depth of Discharge (DoD).
- 99.5% round-trip efficiency for optimized energy storage.
-
Integrated Battery Management System (BMS):
- Built-in safety protections against overcharging, over-discharging, and overheating.
- Supports RS485 and CAN communication for system integration.
-
Scalable Energy Storage:
- Supports up to 16 batteries in parallel for expanded energy capacity.
- Series connections are not supported.
-
High Power Output:
- Max Continuous Charge/Discharge Current: 100A
- Peak Discharge Current: 120A (5s)
-
Temperature Resilience:
- Discharge Range: -20°C to 65°C
- Charge Range: 0°C to 45°C
- Storage Temperature: -10°C to 30°C
-
Durable & Safe Construction:
- Metal case for enhanced durability and protection.
- IP-rated protection for secure energy storage.
Technical Specifications:
- Battery Type: Lithium Iron Phosphate (LiFePO4)
- Nominal Voltage: 51.2V
- Nominal Capacity: 106Ah
- Energy Density: 5.43kWh
- Terminal Type: M6 (Torque: 8.5NM)
- Voltage Window: 44.8V – 57.6V
- Max Charge Voltage: 58.4V ± 0.20V
- Recommended Charge Current: 50A
- Max Continuous Discharge Current: 100A
- Peak Discharge Current: 120A (5s)
- Cycle Life: >4,000 cycles at 80% DoD
- Communication Ports: RS485, CAN, Dryport
-
BMS Safety Protections:
- Primary & Secondary Overcharge Protection
- Primary & Secondary Over-Discharge Protection
- Temperature Protection (Auto Recovery at 85°C)
-
Dimensions & Weight:
- Weight: Approx. 50kg
- Box Dimensions: 550mm x 520mm x 220mm
What’s in the Box?
- 1 x SVOLT 5.43kWh 51.2V 106Ah Lithium Battery
- 1 x Red (Positive) Battery Cable
- 1 x Black (Negative) Battery Cable
- 1 x Communication Cable
- 1 x User Manual
Warranty & Installation Requirements:
- 5-Year Warranty included.
- Installation must be performed by a qualified electrical wireman or master electrician registered with the Department of Labour.
- A valid Certificate of Compliance (COC) must be issued after installation, ensuring adherence to SANS 10142 standards.
- Warranty claims require installation photos, a valid COC, and proof of installation by a certified professional. Failure to comply may result in a voided warranty.
