Description
- Compatible with mains voltage and can charge batteries.
- Auto restart while AC is recovering
- Overload and short circuit protection
- Smart battery charger design for optimized battery performance
- Cold start function
- Pure sine wave inverter
- Built-in solar charge controller
- MPPT Charge Controller
- Operating Temperature Range: -10-50'C
PV INPUT:
Nominal operating voltage 240Vdc Vmax PV:500Vdc
PV input voltage range 60-450Vdc Imax PV:27A
Full load MPPT range 240-450Vdc Rated Power 6200W
Maximum Solar Charging Current 120A
GRID/AC OUTPUT:
Nominal Output Voltage 220/230/240Vac Feed-in Grid Voltage Range 195-253Vac Feed-in Gnd Frequency Range 49-51±1Hz Nominal Output Current: 15 7A Power Factor Range >0.99
Maximum Conversion Efficiency (DC/AC).97% Nominal Operating Frequency 50/60Hz
TWO LOAD OUTPUT POWER:
Full Load 3500W
Maximum Main Load:3500W Maximum Second Load 1166W Main Load Cut Off Voltage:22Vdc Main Load Voltage 26Vdc AC INPUT:
Nominal operating voltage 230Vac Maximum input current 30A
Nominal operating frequency 50/60Hz Surge power 7000VA
Maximum AC Charging Current 100A BATTERY:
Battery voltage range 20-33Vdc Maximum battery current 150A
Size:
440 X 355 X 115
9kg
5 YEAR REPAIR WARRANTY
What's in the box
1 x Inverter
1 x User Manual
